HIGHRISE Ultra 360° is a brand new improved filter with oil separation; effective filtration combined with agronomy. The original construction of the filter ensures very effective filtration. Gas entering the filter is set in rotary motion and directed towards the bottom. Thanks to the rotary motion, centrifugal force and inertial force, particular and liquid matters are centrifuged and kept on the bottom. Additionally, the filter cartridge cleans the stream of gas heading upwards from the remaining tiny impurities. HIGHRISE 360° was designed especially for the convenience of the installers. The inlet and outlet are placed on separate elements of filter cover, which results in easy angle regulation between them. Because of such solution the installer can easily and freely place the filter in the under bonnet area.



TECHNICAL SPECIFICATION

Cover Material: Polyamide and glass composite
Filtrating Material: Polyester
Inlet and Outlet Diameter: 12mm
Classification: CLASS#2
Classifying Pressure: 4.5 bar
Working Temperature: -20°C to 120°C
Dimensions: 60mm x 60mm
(110mm when inlet and outlet are set at 180°) x 106mm
